Accord Technology llc                                    NexNav TM
   GNSS Sensor Technology                                               location... location... location
Your Subtitle text

At the heart of industy's first and only US FAA TSO-C145c ... NexNav GPS WAAS Class Beta-1, -2, -3 to RTCA DO-229D

The Accord Technology NexNavTM GNSS product line now revolves around two key receivers, NexNav mini and NexNav MAX.


The Avionics OEM GPS WAAS reciever/sensor of choice.


The receivers are designed to be at the heart of an embedded customer solution as a Circuit Card Assembly (CCA) or embedded in our own Line Replacement Unit (LRU) as a stand-alone GPS solution. As with all our receivers, we are compatible with other Satellite Based Augmentation System (SBAS) solutions such as EGNOS in Europe and GAGAN in India.

GPS WAAS receiver CCAs (circuit card assemblies) are available in standard form factors or can be adapted to fit your form factor and I/O interface.

NexNav MAX



NexNav mini



NexNav LRU (Line Replaceable Units)

Our Class Beta-1 ("mini") is Pin-For-Pin Replacement For FreeFlight 1201 - GPS Position, Velocity, Time for TAWS, FMS, ADS-B Position, Others ... Where the very latest standards are required

NexNav MAX

Whether it’s a need for L/APV1 approach precision or highly reliable PVT2, NexNav MAX offers standard and custom solutions according to needs. Designed around a small form-factor, the NexNav MAX CCA is provided ready to integrate into host avionics systems, an LRU sensor or as a standalone module to ARINC 743 requirements. We can even package the CCA in a module tailored to your application.

 NexNav mini

 A new product, the NexNav mini, is aimed at providing a very affordable solution for those applications needing only WAAS Class Beta-1 capability, such as ADS-B. As such, the NexNav mini is a GPS WAAS Class Beta-1 only. It is a low power, small CCA (Circit Card Assembly) form factor, US FAA certifiable GPS-SBAS receiver that can be embedded in host avionics or as the heart of our NexNav LRU (Line Replaceable Unit).

Accord Technology LLC
347 Edgewood Lane - Suite 180
Eagle, Idaho - USA 83616 - Voice: +1-208-939-7901 Fax: +1-208-939-7904
